Overview

Max Recording Resolution: 8MP
– Channels: 16CH
– LAN Ports: 1
– SATA: 2X SATA PORTS
– Video Outputs: HDMI / VGA
– NDAA Compliant: Yes
– Hardware Features: Alarm in, Alarm out, Audio in, Audio out, BNC Video Out

Features

16 CH TVI / AHD video input, support 8MP / 5MP/ 4MP / 3MP / 1080P / 720P / WD1
16 CH CVI video input, support 4MP / 3MP / 1080P / 720P / WD1
16 CH DVRs support 8 CH IPC 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
Adopt standard H.265 high profile compression format to get high-quality video at a much lower bit rate
Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
Multi-mode recording: manual / timer / motion
Playback: 16CH simultaneous playback
Search: time slice, time, event ( manual, motion ), tag search
Express and flexible backup via USB, network and so on
Pentaplex: preview, record, playback, backup, and remote access
DHCP, DDNS, PPPoE network protocol, IE browse and CMS supported
Remote control via IE or CMS: preview, playback, backup, PTZ and configuration
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with the mobile device
Multi-user online simultaneously
Authorization management, log review and device status review
HDMI 4K output, true high-resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QR Code scanning by mobile phone and PAD
Powerful smartphone & Pad surveillance with iOS and Android OS

Specifications

System Compression	H.265 High profile
Main Processor	Embedded Processor
Operating System	Embedded Linux
Video Compatibility	HD-TVI / AHD / CVI 4K@15fps, 5MP@20fps, 4MP/3MP/1080P/720P/WD1@30fps (live)
Max. Video Channels	16CH
Video Input	BNC x 16
IP Camera Input	8 (UP TO 16CH)
IPC Resolution	8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
IPC Frame Rate	25fps ( PAL ) / 30fps ( NTSC )
Video Interface	HDMI/VGA/CVBS
Video Resolution	HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
Multi-Screen Display	N/A
OSD	No
Audio In	8CH, RCA
Audio Out	1CH, RCA
2 Way Audio	Take up channel one as an audio input
Recording Resolution	4K/4Klite/5MP/5MP Lite/4MP/4MP Lite/1080P/720P/WD1
Recording Frame Rate	4K@6/7fps(PAL/NTSC) 4K Lite@12fps/15fps(PAL/NTSC) 5MP@12fps (PAL / NTSC) 5MP Lite@20fps (PAL / NTSC) 4MP@12fps(PAL) / 15fps (NTSC) 4MP Lite/1080P/720P/WD1@25fps (PAL) / 30fps (NTSC)
Recording Encode	N/A
Recording Quality	N/A
Recording Mode	Manual, Timer, Motion
Recording File Management	N/A
Playback Channels	16CH
Playback Search	Time slice / time / event / tag search
Playback Smart Search	Highlight colors to display the camera record in a certain period of time, different colors refer to different record events
Playback Function	Play, pause, FF, FB, digital zoom, etc.
Alarm In	16 CH
Alarm Out	4 CH
Alarm Mode	Manual, motion, exception
Trigger Events	Record, snap, alarm out, e-mail, etc.
Network Bandwidth	80/96Mbps
Network Function	TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Network Max. Users	N/A
Mobile	iPhone, Android
Cellphone Function	N/A
RS485	RS485 x 1, connect to PTZ or keyboard
USB	2 x USB 2.0
Remote Connections	Optional
Power Supply	DC12V / 4A
Power Consumption	＜30W (without HDD)
Internal HDD	2 x SATA (up to 10TB capacity for each disk)
e-SATA	e-SATA x 1
Operating Conditions	-10~50°C, 10%~90% (Humidity)
Dimensions	380mm x 268mm x 52mm (W x D x H)

6624

3 - Year Manufacturer Warranty
